QUINT-PS/ 1AC/24DC/ 3.5
13
Output
CAUTION
Make sure that all output lines are dimensioned
according to the maximum output current or are
separately protected. The cables on the
secondary side must have sufficiently large
cross sections in order to keep the voltage
drops on the lines as low as possible.
Ou
13 t DC 2
DC
OK -
3,5
tpu
14 4V
Ι <
Ι N
-
+
A
+
The connection is established using screw connections on
the screw connection of the DC output:
24 V DC: "+" and "–"; DC OK switching output active: "DC OK"
and "–"; DC OK output floating: "13" and "14"; POWER
Bo
DC
o s t
OK
BOOST switching output active: "I < I N " and "–".
At the time of delivery, the output voltage is 24 V DC. The
18-
2 9 ,5
V
output voltage can be set on the potentiometer.
AC
-24
Inp
ut
L
100
N
0V
PE
Protection of the secondary side
The device is electronically protected against short circuit and
idling. In the event of a malfunction, the output voltage is
limited to 35 V DC.
14
Signaling
An active signal output DC OK, a floating signal contact DC OK and an active signal output POWER BOOST are available
for function monitoring. In addition, the DC OK LED and the BOOST LED can be used to evaluate the function of the power
supply directly at the installation location (see output characteristic curve).
I < I N
I > I N
U OUT < 0.9 x U N
"DC OK" LED
"BOOST" LED
Active DC OK switching
ON
OFF
ON
ON
ON
ON
Flashing
ON
OFF
output
Floating DC OK output
Active POWER BOOST
Closed
ON
Closed
OFF
Open
OFF
switching output
Meaning
103126_en_05
Normal operation of the
power supply
(U OUT > 21.5 V)
POWER BOOST operation,
e.g. to start loads
Overload mode, e.g.
consumer short circuit or
overload
PHOENIX CONTACT
12
